Honeywell Q314A3513 Pilot Burner
As a veteran HVACR contractor, you know that a reliable standing pilot is the heartbeat of a natural gas furnace or boiler. The Honeywell Q314A3513 Pilot Burner is a non-primary aerated, target type pilot burner engineered for steady performance in main burner ignition systems. This specific model features a single tip style with a front-facing flame direction, ensuring precise alignment with the main burner for rapid, consistent ignition. Equipped with a 0.018-inch orifice (BCR-18), it is calibrated specifically for natural gas applications, delivering a stable flame pattern that effectively envelops the thermocouple or thermopile tip.
The Honeywell Q314A3513 is built with a Type A mounting bracket and utilizes a standard 1/4-inch compression fitting for seamless integration into existing gas lines. It is technically identical to part numbers 1160046 and Q314A3513/U, making it a direct-drop replacement for aging or failing pilot assemblies. Because it is non-primary aerated, it is less susceptible to linting and clogging, maintaining its front tip pilot flame integrity even in demanding residential or light commercial environments. When you are looking for a replacement gas pilot assembly that minimizes nuisance service calls, the Q314A3513 natural gas pilot provides the robust construction and technical accuracy required for professional HVACR maintenance.
Key Benefits for Contractors- Direct Compatibility: Replaces Honeywell 1160046 and Q314A3513/U without the need for field modifications.
- Precision Metering: Features a factory-installed 0.018" insert orifice for optimized fuel-to-air ratios in natural gas systems.
- Durable Mounting: Includes a rigid Type A bracket for secure positioning on the main burner, preventing flame shift over time.
- Versatile Pairing: Fully compatible with Q309, Q340, and Q390 thermocouples or Q313 thermopiles.
- Reduced Maintenance: The non-primary aerated design minimizes debris buildup, ensuring a cleaner standing pilot burner flame.
Is this pilot burner compatible with LP gas systems?
The Honeywell Q314A3513 is factory-configured for natural gas with a BCR-18 orifice. To convert this unit for liquid propane, a color-coded LP orifice (typically BBR-10) must be swapped in to maintain proper burner ignition safety and performance.
What should I check if the pilot flame is too small?
First, ensure the gas pressure is at the manufacturer's spec. If pressure is correct, check the 0.018-inch orifice for obstructions. Since this is an insert orifice type pilot burner, you can remove the compression fitting to inspect or replace the orifice without discarding the entire assembly.
Can I use this to replace a "wing" style pilot?
No, this model uses a single tip style (target type). Always verify the original mounting footprint and tip direction (Front) to ensure the flame properly hits the thermocouple and the main burner ignition port.
