Heil Quaker ICP 1185076 Motor
Optimize your heat pump or AC system with the Heil Quaker ICP 1185076 Motor, a heavy-duty OEM replacement condenser fan motor engineered for precision airflow and long-term reliability in demanding environments. This 1/4 HP HVAC motor is specifically designed to fit high-performance International Comfort Products units, including select Heil, Arcoaire, and Tempstar models. Operating at a dual-speed range of 1100/900 RPM, this motor provides the necessary torque to pull ambient air across condenser coils, preventing system overheating and maintaining proper head pressure. Built for 208-230V 60Hz and 220V 50Hz electrical configurations, this single-phase PSC motor ensures a direct-drop fit for contractors requiring exact electrical and mechanical specifications. Using a genuine ICP 1185076 motor eliminates the mounting and rotation issues common with generic aftermarket alternatives, ensuring your residential or light commercial split system operates at peak efficiency during high-load cycles.
Key Benefits for Technicians:- Broad Compatibility: Direct replacement motor for Heil 1185076 and ICP 1185076 specs, fitting PHD4 and other popular outdoor series.
- Dual-Speed Efficiency: Rated at 1100/900 RPM to match original airflow requirements and preserve refrigeration cycle integrity.
- Robust Electrical Design: Optimized for 208/230V single-phase power with the thermal HVAC part resilience needed for summer peak loads.
- Simplified Installation: Standard frame and shaft dimensions reduce field modification time for faster service calls.
What are the signs of a failed ICP 1185076 condenser motor?
Common indicators include the outdoor unit humming without fan movement, abnormal grinding noises from worn bearings, or the system shutting down via a high-pressure switch due to insufficient heat dissipation.
Does this motor replace an 825 RPM or 1075 RPM motor?
No. It is critical to match the RPM exactly. This motor is a 1100/900 RPM design. Using it to replace an 825 RPM motor can cause improper airflow and lead to premature compressor failure.
Is a new capacitor required with this motor?
Technicians should always test the current run capacitor. If the capacitance has drifted outside of the ±5% range, or if you are following best practices for motor longevity, a new capacitor matching the 1185076 nameplate rating is recommended.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
