Heil Quaker ICP 1172711 Fan Blade
The Heil Quaker ICP 1172711 Fan Blade is a critical OEM replacement part designed for high-performance heat pump and condensing units. Engineered with a 20-inch diameter and a 20-degree pitch, this 2-blade condenser fan is specifically balanced to optimize airflow across the outdoor coil, ensuring the refrigerant heat exchange process remains within design parameters. This specific 1172711 model features a 1/2-inch bore and is configured for clockwise (CW) rotation, making it a direct match for various International Comfort Products (ICP) brands including Tempstar, Comfortmaker, and Arcoaire.
For technicians performing a motor swap or resolving high-static pressure issues, verifying the Bore Size: 1/2" and the Blade Pitch: 20 Degrees is essential to prevent motor overloading or insufficient CFM. Constructed from heavy-gauge aluminum for corrosion resistance, this condenser fan blade replacement maintains structural integrity during high-RPM operation. When installing, ensure the set screw is torqued correctly to the motor shaft flat to eliminate vibration and premature bearing wear in the condenser motor.
Key Benefits:- Precision Balanced: Factory-rated to reduce vibration, protecting the motor bearings and reducing decibel levels.
- OEM Compatibility: Precision-fit for ICP family units, ensuring the 20-inch blade span matches the original shroud clearance.
- High-Efficiency Pitch: The 20-degree blade angle is optimized for consistent head pressure management in demanding ambient conditions.
- Durable Construction: Built to withstand outdoor exposure and high-velocity air movement without flexing or pitching out of spec.
- How do I verify the rotation of the 1172711 fan blade? This CW rotation fan blade is determined by looking down at the discharge side of the fan; the blades must move clockwise to pull air through the coil and exhaust it upward.
- Can I use this on a 5/8-inch motor shaft? No, this part is designed strictly for a 1/2-inch motor shaft bore. Attempting to bore out the hub will ruin the balance of the assembly.
- What happens if the pitch is different from my original blade? A different pitch will change the amp draw on your condenser motor. Always use the 1172711 to match the original 20-degree pitch to avoid tripping the thermal overload.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
